RUITOOL Cabinet Door Mounting Jig for Frameless Cabinets
Frameless only · Clamps 7 to 40 mm
from$29.59
Cabinet Jigs · 7 holes, 2-in-1
RUITOOL 7-Hole Shelf Pin Jig with Hinge Guide
$42.49
7-hole jig with hinge guide
Two cabinet jobs in one aluminum plate. It drills seven shelf pin holes at a time and lays out 35 mm hinge cups.
- Holes per pass
- 7, spaced 1-1/4 in
- Pin sizes
- 1/4 in (6 mm) and 5 mm
- Edge distance
- 37, 50 or 64 mm
- Hinge guide
- 35 mm cup, 3 to 6 mm from the edge, screw patterns 48 x 6 and 45 x 9.5 mm
Fits
- 1/4 in and 5 mm shelf pins
- Common 35 mm concealed hinges
Checkout, payment and delivery happen with our retail partner. Price from our update of 1 October 2026. How we update prices
What it does
The 7-Hole Shelf Pin & Hinge Jig, in three points
Seven holes at 1-1/4 in
The spacing matches standard shelf pin layouts. A positioning pin extends the row.
Hinge template built in
It guides a 35 mm cup 3 to 6 mm from the edge, with screw patterns of 48 x 6 and 45 x 9.5 mm.
Two bit sizes
Hardened bits for 1/4 in and 5 mm pins come with a stop collar.
Specifications
- Holes per pass
- 7, spaced 1-1/4 in
- Pin sizes
- 1/4 in (6 mm) and 5 mm
- Edge distance
- 37, 50 or 64 mm
- Hinge guide
- 35 mm cup, 3 to 6 mm from the edge, screw patterns 48 x 6 and 45 x 9.5 mm
- Body
- Aluminum alloy
- In the box
- Jig, two drill bits, stop collar, positioning pin
At the bench
Build one cabinet and you drill shelf holes inside and hinge cups on the door. This jig handles both, which saves buying and storing two tools. For shelves, you set the edge distance at 37, 50 or 64 mm and drill through the guides. For hinges, you flip to the template and mark the cup and its screws. The plate is aluminum alloy with a wear-resistant surface.
Check before you buy
- Your shelf pins are 1/4 in or 5 mm.
- Your hinges use a 35 mm cup with 48 x 6 or 45 x 9.5 mm screw spacing.
- You are building a few cabinets, not a full kitchen.
Limits
Pick another one if
It is a layout guide for hinges, and it does not clamp and drill the cup the way our 35 mm hinge jig does. For a full kitchen of doors, that jig is quicker and catches the dust. For long columns of shelf holes, the 11-hole jig covers more in each pass. This one suits a single cabinet or a small run.
Same bench
RUITOOL Cabinet Jigs
7 tools, from $9.99. Set them side by side in one table.
All 7 RUITOOL Cabinet JigsFrom the same bench
More RUITOOL tools
Tools that share a bench or a job with the 7-Hole Shelf Pin & Hinge Jig.
5/64 to 7/16 in bits
RUITOOL Drill Bit Stop Collar Set, 2 Pieces
Bits 5/64 to 7/16 in · Aluminum, nylon ring
$19.99
From buyers
What buyers say about the 7-Hole Shelf Pin & Hinge Jig
4.7 out of 5 from 170 ratings. Reviews word for word, with the critical ones left in.
Works great! Quality tool.
This jig worked very well for my cabinet project. It clamped solidly to the surface and didn't shift accidentally at any point. The pin holes were straight and snug with the standard commercial pins. The two hole size options are excellent, as well as the adjustability of the hole distance. The jig overall feels very solid and like it will last a long time if taken care of.One note for carpenters. If you're drilling into plywood, it's worth pinning a thin sheet of mdf or hardboard on top of your plywood when drilling with this jig. The provided drill bits create some tear out that would be minimized by a top layer. Alternatively, you could try using a different set of bits than the ones supplied, but I don't know if that would stop the problem completely.
Easy to use
This jig was easy to use and it included the drill bits required for drilling the shelving holes. I was adding a long row of shelf peg holes and was trying to match them with the row already present on the board... at first I just tried measuring the distance at which to start drilling the holes... it was off a tiny bit... I would totally suggest using a large square to accurately measure where to start the drilling... once the first hole is drilled, that same hole is used to measure alll the other holes... it was easier than I thought and the jig is well made and will last a long time.
Nice jig for the price, all metal no plastic. only
The tool worked perfect. My only suggestion is that they should make it twice as long so you don't have to move it so much, it only drills about 8" of holes at a time. The second thing is and this is not a complaint make sure you use a clamp in the middle to hold it tight while you drill. The two thumb screws are for holding it to the edge of the board, not for clamping. The tourqe of the drill bit will want to pull it off the edge of the board. This tool is a good bang for the $.
Very good for the money, works with assembled cabinets.
I was surprised how solid this was. I needed to drill out shelf pin holes for a simple rough shop cabinet made from spare wood. This looked like it would work on an already assembled box and it did. The provided bits are not great but they made it through this job, just be sure to really tighten the collar, because it slipped at first and went all the way through one hole. When I drilled the middle vertical panel the holes lined up perfectly from both sides. I can't see anything wrong with this, it might not hold up for making a lot of cabinets but time will tell.
Questions
7-Hole Shelf Pin & Hinge Jig: answers
What is the hole spacing?
The seven holes are 1-1/4 in apart, center to center.
Which hinges does the template match?
Common 35 mm concealed hinges, with the cup 3 to 6 mm from the door edge.
Is a stop collar included?
Yes, along with the two drill bits and a positioning pin.
The RUITOOL range
RUITOOL Cabinet Jigs in one place
Jigs for hanging doors, drilling hinge cups, spacing shelf pins and setting drawer slides. 7 tools, from $9.99.
